6al 4v titanium sheet
Material Standard: AMS 4911, ASTM B265, MIL-T-9046J
Alloy Composition: Ti-6Al-4V (UNS R56400)
Condition: Annealed, Hot Rolled, Cold Rolled (Customizable)
Thickness Range: 0.5mm – 50mm (0.02" – 2.0")
Width Range: 500mm – 1500mm (20" – 60")
Length Range: 1000mm – 3000mm (40" – 120")
Ti-6Al-4V Titanium Sheet (AMS 4911 / UNS R56400) | High-Strength Aerospace-Grade Alloy
Premium Grade 5 Titanium Sheets for Demanding Applications
Our 6al 4v titanium sheet are manufactured to AMS 4911, ASTM B265, and MIL-T-9046 standards, offering the perfect balance of high strength, lightweight properties, and exceptional corrosion resistance. These sheets are the material of choice for:
✔ Aerospace & Defense – Aircraft skins, engine components, missile structures
✔ Medical Implants – Biocompatible (ISO 5832-3 compliant)
✔ Marine & Offshore – Superior seawater corrosion resistance
✔ Chemical Processing – Withstands acids, chlorides, and extreme pH
✔ High-Performance Automotive – Lightweighting for racing and EVs
Common Specifications:
- AMS 4911 – Sheet & Plate (Annealed)
- DMS 1592
- ASTM F 1472 – Bars, Forgings, Sheet, Strip, and Plate
- ISO 5832-3 – Wrought Alloy
- ASTM B-348 – Bars, Forgings
- ASTM B265 – Sheet & Plate
- MIL-T-9046 – Sheet & Plate
- AMS-T-9046 – Sheet & Plate
- AMS-H-81200 – Heat Treating Spec
- ASTM B265 Grade 5
- ASTM SB265 Grade 5
- CMMP015 Cessna
Key Product Specifications
| Parameter | Specification |
|---|---|
| Material Standard | AMS 4911, ASTM B265, MIL-T-9046J |
| Alloy Composition | Ti-6Al-4V (UNS R56400) |
| Condition | Annealed, Hot Rolled, Cold Rolled (Customizable) |
| Thickness Range | 0.5mm – 50mm (0.02" – 2.0") |
| Width Range | 500mm – 1500mm (20" – 60") |
| Length Range | 1000mm – 3000mm (40" – 120") |
| Tensile Strength | 895 MPa (min) |
| Yield Strength | 828 MPa (min) |
| Elongation | 10% (min) |
| Surface Finish | Mill Finish, Pickled, Polished (Ra ≤ 0.4μm) |
| Certifications | EN 10204 3.1, RoHS, REACH, NADCAP (upon request) |
Why Choose Our Ti-6Al-4V Titanium Sheets?
1. Unmatched Material Performance
-
45% lighter than steel with equivalent strength – ideal for weight-sensitive applications
-
Excellent fatigue resistance – outperforms aluminum and stainless steel in cyclic loading
-
Biocompatible & non-toxic – Meets ASTM F136 for surgical implants
2. Rigorous Quality Control
-
Ultrasonic testing (ASTM E2375) for internal defects
-
Full material traceability with mill test reports (MTRs) including heat number
-
Third-party lab verification available (SGS, Bureau Veritas)
3. Customization & Value-Added Services
-
Laser/waterjet cutting to your drawings (tolerance ±0.1mm)
-
Heat treatment options – Annealing, stress relieving, solution treating
-
Special packaging – Moisture-proof for medical applications
Available Sizes & Pricing
Standard Stock Sizes (Custom Sizes Available):
| Thickness (mm) | Width (mm) | Length (mm) | Price (per kg) | Lead Time |
|---|---|---|---|---|
| 1.0 | 1000 | 2000 | $85.00 | 7 days |
| 2.0 | 1200 | 2400 | $78.50 | 10 days |
| 5.0 | 1500 | 3000 | $72.00 | 14 days |
| 10.0 | 1000 | 2000 | $68.00 | 21 days |
Volume Discounts:
-
5-10% off for orders >500kg
-
10-15% off for orders >1000kg
Industry Applications with Case Studies
Case Study 1: Aircraft Structural Components
Customer Challenge: Needed to reduce wing skin weight without compromising strength
Our Solution: 2.5mm 6al 4v titanium sheet with optimized heat treatment
Result: 18% weight savings vs aluminum, passed FAA fatigue testing
Case Study 2: Chemical Reactor Liners
Customer Challenge: 316L stainless steel corroded in HCl vapor environment
Our Solution: 6mm pickled Ti-6Al-4V sheets with welded joints
Result: 7+ years service life with no maintenance
FAQ – Answering Key Buyer Questions
Q: How does Ti-6Al-4V compare to CP Titanium (Grade 2)?
→ A: 2x higher strength but slightly less formable. Ideal where the strength-to-weight ratio is critical.
Q: Can you supply sheets with AMS 4911 certification?
→ A: Yes – All our aerospace sheets include full AMS certification with traceable heat numbers.
Q: What's the maximum width available?
→ A: Standard up to 1500mm, but we can source 2000mm wide sheets with 8-week lead time.
Q: Do you provide material test reports?
→ A: Every sheet ships with EN 10204 3.1 certificate including chemical analysis and mechanical properties.
Limited-Time Offer for New Customers
Order before [date] and receive:
✅ Free material selection consultation with our PhD metallurgist
✅ Discounted first article inspection (25% off dimensional checks)
✅ Priority production scheduling for rush orders
Contact our titanium specialists today:
📞 +86-29-89506568 | ✉ linhui@lhtitanium.com
Instant 6al 4v titanium sheet Quote Tool: [Upload Your Requirements]
