Titanium Alloy UNS R56400

High-Performance Titanium Alloy UNS R56400 from LINHUI TITANIUM

Titanium Alloy UNS R56400 (Ti-6Al-4V Grade 5) represents the industry's most versatile alpha-beta alloy, delivering exceptional strength-to-weight ratio and corrosion resistance across multiple product forms. LINHUI TITANIUM supplies precision-engineered UNS R56400 conforming to Sheet/Plate: ASTM B265 Gr5, Bar/Rod: ASTM B348 Gr5, Castings: ASTM B367 Gr5, Forgings: ASTM B381 Gr5, Implant Grade: ASTM F136 Gr5, Nuts: ASTM F467 Gr5, and Bolts: ASTM F468 Gr5.

With pliable quality ≥895 MPa and abdicate quality ≥828 MPa, our UNS R56400 items accomplish 45% weight lessening versus steel whereas keeping up basic astuteness in temperatures up to 400°C. Each bunch experiences 100% NDT assessment with full EN 10204 3.1 traceability, guaranteeing zero-defect conveyance for your basic applications.

Key Features & Benefits

Superior Mechanical Execution: Thickness of 4.43 g/cm³ gives fabulous strength-to-weight optimization for aviation and car structures.

Exceptional Erosion Resistance: Performs dependably in marine chloride situations and chemical handling media where conventional combinations fail.

Heat Treatment Capability: STA (Arrangement Treated and Matured) prepare improves quality properties for requesting applications.

Biocompatible Brilliance: ASTM F136 review meets FDA necessities for surgical inserts with decreased push protecting impacts.

UNS R56400 Density

ASTM Grade 5 titanium Mechanical Properties

Ti6Al4V Chemical Composition

Manufacturing Process

Ingot Dissolving: Triple vacuum bend remelting (VAR) disposes of considerations and guarantees homogeneous microstructure.

Hot Working: Controlled producing at 900-1050°C builds up ideal alpha+beta stage conveyance for adjusted ductility and strength.

Cold Rolling: Thickness resilience kept up inside ±0.05mm through accuracy multi-pass rolling operations.

Heat Treatment: Arrangement treatment at 955°C taken after by maturing at 540°C creates top mechanical properties in STA condition.

Quality Inspection

· Ultrasonic Testing (UT): 100% volumetric assessment per ASTM E213 recognizes inside discontinuities

· Eddy Current Testing: Confirms surface astuteness on all bar and tube products

· Tensile Testing: Each warm parcel approved for Rm, Rp0.2, and stretching compliance

· Chemical Examination: OES spectroscopy affirms composition inside detail limits

· Dimensional Confirmation: CMM estimation guarantees geometric precision to ±0.1mm

· Third-Party Certification: SGS, BV, TÜV, DNV assessment accessible upon request

Applications

Aerospace Building: Bulkheads, wing skins, and motor mount brackets advantage from tall weakness resistance and warm solidness up to 400°C.

Medical Gadgets: Orthopedic inserts, cranioplasty plates, and surgical rebellious use biocompatibility and MRI-safe non-magnetic properties.

Marine Frameworks: Seaward oil fix risers, desalination warm exchangers, and submarine frames stand up to setting in hypersaline situations for 20+ year lifecycles.

Chemical Preparing: Reactor vessels and weight channeling handle destructive media where stainless steel encounters push erosion breaking.

Export Markets

Our Titanium Alloy UNS R56400 reaches 60+ countries across North America (USA, Canada), Europe (Germany, France, UK), Middle East (UAE, Saudi Arabia), Southeast Asia (Singapore, Malaysia), and South America (Brazil, Colombia). Long-term partnerships with CEFC, PTT, PETRONAS, and PEMEX validate our global quality consistency.

Why Choose Us?

Coordinate Process Supply: Factory-direct estimating kills brokers whereas keeping up strict quality control all through production.

Rapid Reaction: 4-hour citation turnaround, 24-hour drawing survey, and 3-7 day stock conveyance for critical projects.

Flexible MOQ: Trial orders from 100 kg upheld with 200+ tons stock for quick shipment.

Expert Designing Bolster: In-house metallurgists give fabric determination direction and handle optimization consultation.

Complete Compliance: ISO 9001:2015, PED 2014/68/EU, NORSOK M-650, and FDA-grade certifications guarantee administrative adherence.

Packaging & Shipping

Standard Bundling: Plates wrapped in waterproof paper + wooden cases; bars bundled with steel straps + defensive conclusion caps.

Export Documentation: Commercial receipt, pressing list, EN 10204 3.1 MTC, Certificate of Root, and fumigation certificates included.

Logistics Accomplices: Participation with Maersk, MSC, and DHL guarantees secure conveyance with cargo protections scope.

FAQ

Q: What's the difference between ASTM B348 and ASTM F136 Grade 5?

A: ASTM F136 features extra-low interstitial (ELI) content with oxygen ≤0.13%, providing enhanced biocompatibility for surgical implants compared to standard industrial-grade B348.

Q: Can you provide material test reports?

A: Yes. Each shipment includes EN 10204 3.1 certificates with full chemical analysis and mechanical test data traceable by heat number.

Q: What lead time for custom forgings?

A: Custom product forgings require 25-40 days depending on complexity. Rush service available for critical projects.

Q: Do you accept small trial orders?

A: Absolutely. We support MOQ from 100 kg for stock items, allowing you to evaluate material performance before volume commitments.

Request a Quote

Ready to optimize your project with premium Titanium Alloy UNS R56400 solutions? Contact our technical team at linhui@lhtitanium.com for customized quotations and engineering support tailored to your specifications.
