GR4 titanium plates
Grades of supply:Gr1 ,Gr2 ,Gr5,Gr12
Thickness:5~100mm Width:1200~2500mm
Length:3000~10000mm
GR4 Titanium Plates – High-Strength Corrosion-Resistant Solutions
Premium GR4 titanium plates with outstanding mechanical performance are supplied by LINHUI TITANIUM. Our stock includes several grades (Gr1, Gr2, Gr5, Gr12) with thicknesses between 5 and 100 mm, widths between 1200 and 2500 mm, and lengths between 3000 and 10000 mm. GR4, the strongest commercially pure titanium kind, with exceptional corrosion resistance and a tensile strength of more than 550 MPa. For your crucial applications, our carefully regulated cold rolling process guarantees stable forming performance with thickness tolerance within ±0.05mm. We effectively fulfill your urgent project requests with more than 200 tons of inventory and delivery in 3–7 days.
Key Features & Benefits
Better Ratio of Strength to Weight
Of all the CP titanium grades, GR4 titanium plates are the strongest. You do not need to add weight for your components to support greater loads.
Outstanding Resistance to Corrosion
Seawater, oxidizing acids, and moist chlorine are all prevented by the stable oxide film. In challenging conditions, your equipment lasts longer.
Outstanding Formability
Our plates retain good ductility despite their great strength. Complex shapes can be created without running the risk of cracking.
Specifications For GR4 titanium plates
| Chemical Composition | Mechanical Properties |
|---|---|
|
|
Manufacturing Process
Material Selection
We source high-purity titanium sponge from certified suppliers. Each batch undergoes chemical analysis before melting.
Vacuum Arc Melting
Triple melting eliminates impurities and ensures homogeneous structure. This process guarantees consistent mechanical properties throughout the plate.
Hot Rolling & Cold Rolling
Precision-controlled rolling achieves tight thickness tolerance. Our cold rolling maintains ±0.05mm accuracy for predictable forming behavior.
Heat Treatment
Annealing relieves internal stress and optimizes grain structure. Your plates arrive ready for fabrication without additional treatment.
Quality Inspection
100% NDT Testing
Every plate undergoes ultrasonic and eddy current inspection. We detect subsurface defects before shipment.
Mechanical Testing
Tensile, yield, and elongation tests verify conformance to ASTM B265. Test reports accompany each order.
Dimensional Verification
Automated measurement systems confirm thickness, width, and flatness. Your parts fit perfectly without rework.
Third-Party Certification
SGS, BV, TÜV, and DNV inspection available upon request. Complete traceability documentation provided.
Applications
Aerospace Parts
High strength and temperature resistance up to 400°C are advantageous for ducting systems, bulkheads, and engine cowlings.
Equipment for Chemical Processing
Our GR4 titanium plates are essential for the durability of heat exchangers, reaction vessels, and distillation columns that handle harsh fluids.
Implants in Medicine
Biocompatible materials that can safely support physiological loads are needed for bone plates, screws, and dental fixtures.
Engineering for the Sea
These plates are used as seawater-resistant structural elements in desalination facilities and offshore platforms.
Export Markets
Our goods are available in more than 60 nations, including:
North America: Mexico, Canada, and the United States
Europe: France, Germany, the United Kingdom, and the Netherlands
Middle East: Saudi Arabia, Qatar, the United Arab Emirates
Asia-Pacific: Singapore, South Korea, Japan
South America: Colombia, Ecuador, and Brazil
For long-term supply agreements, we collaborate with significant contractors like as CEFC, PTT, PETRONAS, and LUKOIL.
Why Choose Us
Factory-Direct Pricing
No middlemen means cost savings. You get competitive rates without compromising quality.
Rapid Response
Quotations within 4 hours, drawing review within 24 hours. Your projects stay on schedule.
Flexible MOQ
Trial orders from 100 kg supported. We accommodate both small fabricators and large industrial buyers.
Technical Support
In-house metallurgists assist with material selection and application engineering. You make informed decisions confidently.
Packaging & Shipping
Typical Packaging
Plates are put on wooden pallets after being wrapped in waterproof paper and fastened with steel straps. Edge shields guard against damage while in transportation.
Personalized Crating
We offer ISPM 15-compliant plywood crates for large or expensive shipments.
Options for Shipping
Air freight for urgent needs, sea freight for large shipments. If necessary, we handle door-to-door logistics coordination.
FAQ
Q: What distinguishes Gr2 from Gr4?
A: Gr4 has 40% more tensile strength than Gr2 while retaining comparable corrosion resistance due to its higher oxygen and iron content.
Q: Are plates able to be trimmed to certain sizes?
A: Yes. We provide shear and waterjet cutting services. For a customized quote, enter your measurements.
Q: Do you provide certificates for material tests?
A: Definitely. Every shipment comes with EN 10204 3.1 or 3.2 certificates with complete traceability.
Q: How much is the minimum order quantity?
A: The starting weight for stock items is 100 kg. Higher minimums are needed for custom sizes due to production needs.
Q: Do your GR4 titanium plates meet FDA regulations?
A: Yes. We provide ASTM F67-compliant medical-grade materials for implanted devices.---
Request a Quote
Ready to source high-performance GR4 titanium plates for your project? Contact our team today for technical specifications, pricing, and delivery timelines. Email us at linhui@lhtitanium.com with your requirements. We'll respond within 4 hours to keep your operations moving forward.
