Pure Titanium Wire
Grade: titanium
Ti (Min): 99.95%
Strength: 1300MPa
Processing Service: Bending, Welding, Cutting
Standard: ASTM B863,ASTM F136
Pure Titanium Wire - Premium Grade Titanium Wire Supplier
LINHUI TITANIUM manufactures Pure Titanium Wire conforming to ASTM B863 and ASTM F136 standards, delivering 99.95% minimum titanium purity with tensile strength up to 1300MPa. Our commercially product features an alpha-phase hexagonal close-packed crystal structure, offering exceptional corrosion resistance and biocompatibility for demanding industrial and medical applications.
With precision cold-drawing technology, we maintain diameter tolerances within h7-h9 ISO limits and straightness deviation below 1mm per meter. Full processing services including bending, welding, and cutting are available to meet your exact specifications.
Key Features & Benefits
Our item fathoms basic industry challenges where customary materials fall flat. It disposes of galvanic erosion in marine situations and anticipates heavy-metal particle filtering in biomedical implants.
The fabric gives predominant strength-to-weight proportion for aviation applications whereas keeping up fabulous ductility. You advantage from zero nickel substance, making it perfect for patients with metal sensitivities.
Our wire illustrates extraordinary chemical solidness in chlor-alkali generation and acidic preparing situations. It offers unsurprising formability for complex geometries without compromising auxiliary astuteness.
Pure Titanium Wire Specifications
Chemical Composition (ASTM B863, Grade 1-4)
| Grade | Ti (Min) | Fe (Max) | O (Max) | C (Max) | N (Max) | H (Max) |
|---|---|---|---|---|---|---|
| Grade 1 | 99.5% | 0.20% | 0.18% | 0.08% | 0.03% | 0.015% |
| Grade 2 | 99.2% | 0.30% | 0.25% | 0.08% | 0.03% | 0.015% |
| Grade 3 | 98.9% | 0.30% | 0.35% | 0.08% | 0.05% | 0.015% |
| Grade 4 | 98.5% | 0.50% | 0.40% | 0.08% | 0.05% | 0.015% |
Mechanical Properties
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HV) |
|---|---|---|---|---|
| Grade 1 | 240-370 | 170-310 | 24% min | 120-200 |
| Grade 2 | 345-480 | 275-410 | 20% min | 180-250 |
| Grade 3 | 450-590 | 380-520 | 18% min | 220-300 |
| Grade 4 | 550-740 | 480-650 | 15% min | 250-350 |
Manufacturing Process
We employ precision cold-drawing technology with multiple pass reductions. Each coil undergoes controlled annealing in vacuum atmosphere to eliminate alpha-case contamination.
Surface treatment includes acid pickling to remove oxide layers. Straightening operations utilize roller leveling systems for dimensional accuracy.
Final Pure Titanium Wire passes through laser diameter measurement stations ensuring continuous tolerance verification. All processing maintains strict temperature and atmosphere controls.
Quality Inspection
Each group experiences 100% non-destructive testing utilizing whirlpool current review. We perform dormant gas combination investigation to confirm hydrogen and nitrogen substance underneath basic thresholds.
Tensile testing approves mechanical properties per ASTM necessities. Minuscule surface examination identifies any pass on marks or subsurface defects.
You get EN 10204 3.1 certificates with full warm number traceability. Third-party assessment by SGS, BV, or TÜV accessible upon request.
Applications
· Medical Devices: Surgical sutures, orthodontic archwires, pacemaker leads
· Chemical Processing: Electrode frameworks, reactor vessel tie-wires, warm exchanger components
· Aerospace: Aircraft control cables, latch wire, added substance fabricating feedstock
· Marine Engineering: Seawater corrosion-resistant clasp, subsea hardware springs
· Electronics: Sputtering targets, vacuum tube fibers
Export Markets
We've effectively conveyed to 60+ nations over North America, Europe, Center East, and Southeast Asia. Major clients incorporate chemical processors, restorative gadget producers, and aviation component suppliers.
Our set up coordinations organize guarantees compliant documentation for traditions clearance. We keep up organizations with EPC temporary workers serving worldwide vitality projects.
Why Choose Us?
Direct Process Supply: Factory estimating disposes of agents markup whereas guaranteeing quality control at the source.
Rapid Response: Quotations inside 4 hours, specialized drawing audit in 24 hours maximum.
Flexible Ordering: Stock orders from 100kg least; 200+ tons stock for quick shipment.
Engineering Support: In-house metallurgists give fabric choice interview and application-specific recommendations.
Multilingual Service: English, Chinese, Spanish bolster groups accessible all through your extend lifecycle.
Packaging & Shipping
Wire provided on precision-wound spools or in straight-cut lengths per your detail. Each coil fixed in moisture-barrier film with desiccant protection.
Wooden cases with shock-absorbing insides cushioning for send out shipments. All bundles labeled with warm numbers and fabric certificates.
Stock conveyance inside 3-7 days; custom orders dispatch in 15-25 days. Sped up generation accessible for critical requirements.
FAQ
Q: What's the distinction between Review 1 and Review 2?
A: Review 2 contains marginally higher oxygen substance (0.25% vs 0.18%), giving expanded quality whereas keeping up amazing erosion resistance.
Q: Can you give FDA-compliant material?
A: Yes, our ASTM F136 review meets FDA prerequisites for implantable therapeutic devices.
Q: Do you offer custom breadth tolerances?
A: Completely. We can accomplish more tightly h6 resilience for accuracy applications with balanced lead times.
Q: What's your least arrange quantity?
A: Stock things begin at 100kg; custom details may require higher minimums depending on breadth.
Q: How do you prevent hydrogen embrittlement?
A: Controlled annealing atmospheres and strict hydrogen content monitoring (<0.015%) during production ensure embrittlement-free material.
Request a Quote
Ready to source high-purity titanium wire for your next project with Pure Titanium Wire? Contact our technical sales team at linhui@lhtitanium.com with your specifications.
