What is ASTM F136?

Let me tell you about the gold standard of medical titanium. As a materials engineer who's worked with surgical implants for over a decade, I've seen how ASTM F136 titanium (also known as Ti-6Al-4V ELI) has become the go-to choice for critical medical applications.

This isn't your average titanium. ASTM F136 specifies the extra-low interstitial (ELI) version of the popular 6Al-4V alloy, with tighter controls on impurities like oxygen and iron. It's like the difference between tap water and medical-grade sterile water - similar at first glance, but worlds apart in purity.

Key characteristics:

Used in 80% of orthopedic implants
Contains 6% aluminum, 4% vanadium
"ELI" means extra-low interstitial elements
Meets strict biocompatibility requirements

Is ASTM F136 titanium good?

Good? It's exceptional - and here's why. Last year, I consulted on a knee replacement case where we specifically chose Ti-6Al-4V ELI over cheaper alternatives. The patient, an active 50-year-old, was back to hiking in six months with zero complications.

The numbers speak for themselves:

Property	ASTM F136	Regular 6Al-4V
Oxygen content	≤0.13%	≤0.20%
Fatigue strength	500+ MPa	450 MPa
Biocompatibility	Excellent	Good
Typical uses	Implants	Aerospace

Real-world advantages:
✓ Fewer inflammatory responses
✓ Better long-term performance in the body
✓ Superior fracture toughness
✓ Proven 30+ year track record

What is the ASTM code for titanium?

The ASTM system can feel like alphabet soup, so let me break it down. For medical titanium, these are the codes you'll need:

ASTM F136: The star of our show - implant-grade 6Al-4V ELI
ASTM F67: Pure titanium (Grades 1-4)
ASTM F1295: Ti-6Al-7Nb (alternative alloy)
ASTM F1713: Ti-13Nb-13Zr (for specialized uses)

Pro tip: When sourcing materials, always specify "ASTM F136" - don't just say "medical titanium." I've seen too many instances where suppliers delivered standard-grade materials when implant-grade was required.

What is the difference between grade 23 titanium and F136?

This question comes up constantly in my consulting work. While both are used in medicine, they're not interchangeable. Let me give you the insider's perspective.

Grade 23 (Ti-6Al-4V ELI) is the material designation, while Ti-6Al-4V ELI is the standard that governs how it's processed for medical use. Think of it like:

Grade 23 = the ingredients
ASTM F136 = the recipe for medical applications

Critical differences:

Factor	Grade 23	ASTM F136
Surface finish	Varies	Medical-grade polish
Trace elements	Meets basic specs	Extra controls
Documentation	Standard certs	Full traceability
Cost	$< / t d > < t d s t y l e = " b a c k g r o u n d - c o l o r :$	$
Best for	Some dental implants	Load-bearing implants

Practical advice: If you're making spinal implants? Stick with F136. Dental crowns? Grade 23 might suffice. When in doubt - and especially for FDA submissions - go with the full F136 certification.

Making the Right Choice

After reviewing thousands of cases, here's my simple decision framework:

Is it going inside the body long-term? → ASTM F136
Does it bear weight? → Ti-6Al-4V ELI
Is cost the primary concern? → Consider alternatives

Remember that time we tried to save $200 on a batch of bone screws by using non-F136 material? The revision surgeries cost ten times more. Some lessons you only need to learn once.

Need help specifying materials for your project? Our team offers free consultations to ensure you get the right grade for your application. Because when it comes to medical implants, "good enough" simply isn't.
