Titanium Tee
Specifications: Complete specifications, accept customization
Titanium content: 99.99%
Features: Corrosion resistance, high-temperature resistance, high strength
Physical properties: Metallic luster, ductility
Manufacturing process: Forging, extrusion, rolling, drawing
Titanium Tee – Premium Grade Industrial Pipe Fitting
LINHUI TITANIUM manufactures high-precision Titanium Tee fittings conforming to ASTM B363 standards, with titanium content reaching 99.99%. Our products feature complete specifications and accept full customization to meet your unique project requirements.
Each item is created through progressed producing, expulsion, rolling, and drawing forms, guaranteeing extraordinary erosion resistance, high-temperature resistance, and tall quality. With metallic gloss and predominant ductility, our fittings dispose of push erosion splitting in forceful chloride situations where conventional steel fails.
We keep up 200+ tons stock for prompt conveyance inside 3–7 days. Custom orders transport inside 25–40 days with full EN 10204 3.1/3.2 traceability documentation.
Key Features & Benefits
Our item anticipates disastrous disappointments in high-chloride and oxidizing corrosive situations. You get zero upkeep costs over a 40-year lifecycle compared to stainless steel substitutions each 5–8 years.
The tall strength-to-weight proportion decreases auxiliary stack in seaward stages. Prevalent ductility permits field alterations without splitting risks.
100% NDT assessment (ultrasonic + whirlpool current) ensures zero-defect conveyance. You get leak-proof execution in damp chlorine, seawater, and concentrated acids.
Product Information
| Product name | Titanium Tee |
| Specifications | Complete specifications, accept customization |
| Titanium content | 99.99 |
| Features | Corrosion resistance, high-temperature resistance, high strength |
| Physical properties | Metallic luster, ductility |
| Manufacturing process | Forging, extrusion, rolling, drawing |
| Surface | Anti-rust oil, hot-dip galvanizing, and polishing |
| Packaging | Wooden box |
| Application | Aerospace, chemical, petroleum, pharmaceutical |
| Nominal Pipe Size | Outside Diameter (OD) | Center to Face (A) | |||
| in | mm | in | mm | in | mm |
| 1/2″ | 15 | 0.84 | 21.34 | 1.00 | 25.40 |
| 3/4″ | 20 | 1.05 | 26.67 | 1.13 | 28.58 |
| 1″ | 25 | 1.32 | 33.40 | 1.50 | 38.10 |
| 1-1/4″ | 32 | 1.66 | 42.16 | 1.88 | 47.63 |
| 1-1/2″ | 40 | 1.90 | 48.26 | 2.25 | 57.15 |
| 2″ | 50 | 2.38 | 60.33 | 2.50 | 63.50 |
| 2-1/2″ | 65 | 2.88 | 73.03 | 3.00 | 76.20 |
| 3″ | 80 | 3.50 | 88.90 | 3.38 | 85.73 |
| 3-1/2″ | 90 | 4.00 | 101.60 | 3.75 | 95.25 |
| 4″ | 100 | 4.50 | 114.30 | 4.13 | 104.78 |
| 5″ | 125 | 5.56 | 141.30 | 4.88 | 123.83 |
| 6″ | 150 | 6.63 | 168.28 | 5.63 | 142.88 |
| 8″ | 200 | 8.63 | 219.08 | 7.00 | 177.80 |
| 10″ | 250 | 10.75 | 273.05 | 8.50 | 215.90 |
| 12″ | 300 | 12.75 | 323.85 | 10.00 | 254.00 |
| 14″ | 350 | 14.00 | 355.60 | 11.00 | 279.40 |
| 16″ | 400 | 16.00 | 406.40 | 12.00 | 304.80 |
| 18″ | 450 | 18.00 | 457.20 | 13.50 | 342.90 |
| 20″ | 500 | 20.00 | 508.00 | 15.00 | 381.00 |
| 24″ | 600 | 24.00 | 609.60 | 17.00 | 431.80 |
| Schedule 10S Light N.P.S. | |||||
| Wall Thickness (T) | Inside Diameter (ID) | Approx. Wt. in Pounds/Kgs | |||
| in | mm | in | mm | lb | kg |
| 0.08 | 2.11 | 0.67 | 17.12 | 0.12 | 0.05 |
| 0.08 | 2.11 | 0.88 | 22.45 | 0.16 | 0.07 |
| 0.11 | 2.77 | 1.10 | 27.86 | 0.36 | 0.16 |
| 0.11 | 2.77 | 1.44 | 36.63 | 0.63 | 0.29 |
| 0.11 | 2.77 | 1.68 | 42.72 | 0.86 | 0.39 |
| 0.11 | 2.77 | 2.16 | 54.79 | 1.07 | 0.49 |
| 0.12 | 3.05 | 2.64 | 66.93 | 1.77 | 0.80 |
| 0.12 | 3.05 | 3.26 | 82.80 | 2.23 | 1.01 |
| 0.12 | 3.05 | 3.76 | 95.50 | 3.36 | 1.52 |
| 0.12 | 3.05 | 4.26 | 108.20 | 4.36 | 1.98 |
| 0.13 | 3.40 | 5.30 | 134.49 | 7.69 | 3.49 |
| 0.13 | 3.40 | 6.36 | 161.47 | 10.25 | 4.65 |
| 0.15 | 3.76 | 8.33 | 211.56 | 14.75 | 6.69 |
| 0.17 | 4.19 | 10.42 | 264.67 | 33.75 | 15.31 |
| 0.18 | 4.57 | 12.39 | 314.71 | 49.75 | 22.56 |
| 0.19 | 4.78 | 13.62 | 346.05 | 61.25 | 27.78 |
| 0.19 | 4.78 | 15.62 | 396.85 | 74.25 | 33.67 |
| 0.19 | 4.78 | 17.62 | 447.65 | 96.75 | 43.88 |
| 0.22 | 5.54 | 19.56 | 496.93 | 130.00 | 58.96 |
| 0.25 | 6.35 | 23.50 | 596.90 | 196.00 | 88.89 |
Manufacturing Process
We begin with certified titanium ingots warmed to exact producing temperatures. Hot manufacturing makes the T-shape clear with controlled grain stream for greatest strength.
Seamless expulsion kills weld frail focuses. Rolling operations refine divider thickness resistance to ±0.05mm. Last drawing accomplishes dimensional accuracy.
Stress help tempering at 650–750°C reestablishes ductility. CNC machining guarantees idealize beveling for orbital welding. Each fitting experiences ultrasonic testing some time recently pickling or polishing.
Quality Inspection
· Dimensional check per ASME B16.9 tolerances
· Ultrasonic testing (UT) to ASTM E213
· Eddy current testing for surface defects
· Positive Fabric Recognizable proof (PMI) verification
· Hydrostatic weight testing available
· Third-party review (SGS, BV, TÜV) supported
Applications
Chemical Processing: Chlor-alkali plants, titanium reactors, corrosive conveyance systems
Offshore Oil & Gas: Subsea control umbilicals, stage firewater systems
Aerospace: Hydraulic steering in fuselage frameworks requiring 10,000+ PSI ratings
Pharmaceutical: High-purity bioprocessing where particle defilement is unacceptable
Desalination: Seawater admissions manifolds in SWRO plants
Export Markets
We've delivered Titanium Tee fittings to 60+ countries across North America, Middle East, Southeast Asia, and Europe. Major clients include EPC contractors serving PETRONAS, LUKOIL, and PEMEX projects.
Our products comply with PED 2014/68/EU, NORSOK M-650, and FDA standards for global market access.
Why Choose Us?
Coordinate process supply disposes of agents costs. You get plant estimating with full warm number traceability and MTC documentation.
Flexible MOQ beginning from 100 kg bolsters trial orders. Our designing group gives free fabric determination meeting in English, Chinese, Spanish, and Arabic.
ISO 9001:2015 certified generation guarantees reliable quality. Stock accessibility ensures crisis conveyance inside 72 hours for basic shutdowns.
Packaging & Shipping
Each item is wrapped in defensive froth and fixed in wooden cases assembly ISPM-15 fumigation benchmarks. We give trade documentation counting Commercial Receipt, Pressing List, Certificate of Root, and Fabric Test Certificates.
Shipping choices incorporate discuss cargo for critical orders and ocean cargo for bulk amounts. Express dispatch accessible for samples.
FAQ
Q: Can I weld a item to stainless steel pipe directly?
A: No. Utilize bimetallic move joints to avoid fragile intermetallic formation.
Q: What protecting gas is required amid installation?
A: Utilize 99.999% unadulterated Argon with trailing and backing gas. Any discoloration demonstrates contamination.
Q: How does lifecycle fetched compare to Super Duplex?
A: Beginning taken a toll is higher, but zero erosion remittance and 40-year life expectancy result in lower add up to proprietorship cost.
Q: Is warm treatment required after forming?
A: Yes. ASTM B363 requires push alleviation toughening to anticipate postponed hydride cracking.
Q: What weight can 1/2" Plan 40 handle?
A: Gr2 surpasses 3,000 PSI; Gr5 amalgam withstands 5,000+ PSI depending on temperature.
Request a Quote
Need custom Titanium Tee specifications or technical support? Contact our engineering team at linhui@lhtitanium.com for quotation response within 4 hours. Get your project moving today!
