High-performance ASME B16.5 Long Weld Neck Flange solutions designed for vital pipe systems are produced by LINHUI Titanium. We provide precision-engineered flanges in carbon Asme B16 5 Long Weld Neck Flange (ASTM A105, A350 LF1/LF2/LF3, A694 F42-F70), alloy steel (ASTM A182 F1/F5a/F9/F11/F12/F22/F91, 16MnR, 12Cr1MoV), and stainless steel (ASTM A182 F304/304L/F316/316L, 321, 18-8). Our system quality satisfies TUV, ISO, and SGS requirements. Our ASME B16.5 Long Weld Neck Flange's tapered hub design eliminates turbulence in high-velocity applications while optimizing stress distribution for Class 150-2500 pressure ratings.

Key Features & Benefits

Compared to conventional designs, our Asme B16 5 Long Weld Neck Flange offer better stress distribution because to their longer hub lengths. In high-pressure applications, the progressive taper reduces stress concentration by 40% by strengthening the connecting point.

Erosion-corrosion hazards in high-velocity systems are eliminated thanks to smooth internal bore alignment. Full penetration welding is ensured by the butt-weld connection, providing joint integrity appropriate for thermal expansion and cyclic stress.

These flanges' improved fatigue resistance makes them perfect for vibration-prone settings like power plants and offshore platforms.

 Specifications

For more specific product parameters, please refer to:

• Carbon Steel: ASTM A105, Q235, 16Mn...
• Alloy Steel: ASTM A182 F1, F5a...
• Stainless Steel: ASTM A182 F304, 304L...

Manufacturing Process

To improve mechanical qualities and optimize grain structure, we use precision forging at regulated temperatures. Using CNC technology, the expanded hub is machined with a tolerance of ±0.05mm to ensure excellent bore alignment.

Heat treatment procedures vary depending on the grade of the material; for example, solution annealing is used for stainless steel and normalizing is used for carbon steel. Dimensional verification is performed on each ASME B16.5 Long Weld Neck Flange using ASME B16.5 templates.

For corrosion resistance, surface finishing techniques include passivation and pickling. According to ASME B16.5 requirements, final machining guarantees face flatness within 0.002".

Inspection of Quality

Bolt hole spacing, flange thickness, and hub taper angles are confirmed by 100% dimensional inspection. While magnetic particle inspection (MPI) verifies surface integrity, ultrasonic testing (UT) finds interior flaws.

Every production lot's chemical composition is verified by Positive Material Identification (PMI). Leak-proof performance is ensured by hydrostatic testing at 1.5× design pressure.

On request, third-party examination is offered by SGS, TUV, BV, and DNV. ASME B16.5 compliance records, test reports, and material certificates are examples of complete documentation.

Applications Of Asme B16 5 Long Weld Neck Flange

High-pressure pipelines, offshore platforms, and refinery process lines that require exceptional fatigue resistance due to vibration and pressure cycling are examples of the oil and gas industry.

Chemical Processing: Managing corrosive media in reactor pipework, acid transfer systems, and chlor-alkali plants where leak avoidance is crucial.

Power generation includes heat exchangers, steam lines, and feedwater systems that run at high pressures and temperatures.

Desalination Plants: Long-term corrosion resistance is necessary for high-pressure RO systems and seawater intake piping.
