ASTM F67 Pure Titanium For Surgical Implant

ASTM F67 Pure Titanium For Surgical Implant

The four grades of ASTM F67 Pure Titanium for Surgical Implant that LINHUI Titanium specializes in producing are UNS R50250 (Gr.1), UNS R50400 (Gr.2), UNS R50550 (Gr.3), and UNS R50700 (Gr.4). Our surgical-grade titanium is available in three different sizes: strips that are ≤4.75 mm thick and ≤610 mm wide, sheets that are ≤4.75 mm thick and ≥610 mm wide, and plates that are ≥4.75 mm thick and ≥254 mm wide.

Stable forming performance has been ensured since 2000 by maintaining controlled cold rolling technique with thickness tolerance within ±0.05mm. Every product is subjected to 100% ultrasonic and eddy current NDT inspection, which ensures the zero-defect quality control necessary for biomedical applications.

Key Features & Benefits

With no adverse responses, our Surgical Implant provides excellent biocompatibility. Because of the material's superior osseointegration qualities, normal bone development around implants is encouraged.

Controlled interstitial components will help you avoid embrittlement hazards by keeping the hydrogen level below 0.015%. Under physiological pressures, the ideal fatigue strength is guaranteed by the fine equiaxed grain structure (usually G5 or finer).

Grade 4 offers total corrosion immunity in bodily fluids and tensile yield strength that is comparable to stainless steel. Brittle layers that lead to the development of fatigue cracks are eliminated by our zero alpha-case surface.

Manufacturing Process

To ensure chemical homogeneity and remove impurities, our surgical implant titanium is vacuum arc remelted (VAR) three times.

Surface oxidation is avoided by hot rolling in chambers with an inert environment. After that, controlled cold rolling is used to achieve the exact thickness tolerances needed for implant manufacturing.

Fine grain structures are produced via stress relief annealing at regulated temperatures. Remaining scale is eliminated by final pickling without adding impurities. For complete traceability, each coil is laser-marked with a heat number.

Quality Inspection

Every batch undergoes ICP-OES chemical analysis, verifying exact interstitial element levels. Microstructure evaluation confirms alpha-phase grain uniformity per ASTM E112 standards.

100% ultrasonic testing (AMS 2631 Class A1) detects internal voids exceeding 0.3mm. Tensile and bend testing per ASTM E8/E290 validates mechanical properties.

Surface cytotoxicity screening and LAL endotoxin testing ensure biocompatibility. EN 10204 3.2 certificates accompany each shipment with complete heat traceability.

Applications Of ASTM F67 Pure Titanium For Surgical Implant

ASTM F67 Pure Titanium For Surgical Implant serves in orthopedic joint replacements, dental implants, and spinal fusion devices. You'll find it in craniofacial reconstruction plates and cardiovascular stents.

Grade 4's higher strength suits load-bearing hip stems and tibial plates. Grades 1-2 excel in thin-walled dental abutments requiring superior formability.

Export Markets

We've delivered surgical titanium to medical device manufacturers across USA, Germany, Switzerland, Japan, and South Korea. Our materials support production facilities in 40+ countries throughout North America, EU, and Southeast Asia.

Why Choose Us

Direct mill supply eliminates middlemen, reducing your procurement costs by 15-20%. Our 200+ ton stock inventory enables 3-7 day delivery for urgent orders.

In-house metallurgists provide material selection consultation based on your specific implant design. Multilingual support team responds to quotations within 4 hours.

Flexible MOQ starts at 100kg for trial orders. FDA-compliant grades available with REACH/RoHS documentation.

Packaging & Shipping

Materials are wrapped in moisture-proof paper with VCI anti-corrosion protection. Wooden cases meet ISPM 15 fumigation standards for international shipping.

Each package includes MTC documentation, inspection reports, and heat number labels. Sea freight and air shipping options available based on your timeline requirements.

FAQ

Q: What's the difference between Grade 2 and Grade 4?

A: Grade 4 contains higher oxygen content (0.40% vs 0.25%), providing 60% greater yield strength while maintaining biocompatibility.

Q: Do you provide material traceability?

A: Yes, every product includes EN 10204 3.2 certificates with complete heat number tracking from ingot to finished product.

Q: What's your minimum order quantity?

A: We support trial orders starting from 100kg. Stock items ship within 3-7 days.

Q: Can you provide custom dimensions?

A: Absolutely. Custom thicknesses, widths, and surface finishes available with 25-40 day lead time.

Request a Quote

Ready to source certified ASTM F67 Pure Titanium For Surgical Implant for your medical device manufacturing? Contact our engineering team at linhui@lhtitanium.com for technical specifications, pricing, and samples. We'll respond within 4 hours with tailored solutions for your project.
