Why choose high-purity zirconium 60702 plate?
High purity zirconium 60702 plate (99.9%) is a highly respected special metal material in today's industrial field, known for its excellent corrosion resistance, excellent mechanical properties and outstanding biocompatibility. This zirconium plate with a purity of 99.9% plays an irreplaceable role in high-end fields such as chemical, medical, aerospace and nuclear industries.
Key features of high-purity zirconium 60702 plate
1. Extraordinary corrosion resistance
High-purity zirconium 60702 plate (99.9%) shows strong resistance to most acid, alkali, and salt solutions, especially under high temperature and high pressure environments, its corrosion resistance far exceeds traditional materials such as stainless steel and titanium alloy.
2. Excellent mechanical strength
Tensile strength: ≥550 MPa
Yield strength: ≥380 MPa
Elongation: ≥16%
3. Excellent thermal properties
Melting point: 1852°C
Coefficient of thermal expansion: 5.7×10⁻⁶/°C (20-400°C)
Thermal conductivity: 22 W/(m·K)
4. Unique nuclear properties
Zirconium has an extremely low thermal neutron absorption cross section, making it an ideal material for nuclear reactor fuel rod cladding.
Technical parameters for purchasing high-purity zirconium 60702 plates (99.9%)
| Parameters | Index |
| Purity | ≥99.9% |
| Density | 6.49 g/cm³ |
| Hardness (HV) | 140-200 |
| Surface roughness (Ra) | ≤0.8μm (adjustable upon request) |
| Plate thickness | 0.5mm - 50mm (customizable) |
| Plate width | ≤1200mm |
| Plate length | ≤3000mm |
Quality Assurance and Certification
The high-purity zirconium 60702 plates we provide comply with the following international standards:
ASTM B550
ISO 9001:2015
ASME SB550
EN 10204-3.1
Each batch of products comes with a complete material certificate and test report to ensure that the material performance meets the most stringent industrial requirements.
FAQ
Q: What is the difference between high-purity zirconium 60702 plates and ordinary zirconium materials?
A: High-purity zirconium 60702 plate (99.9%) has lower impurity content than ordinary zirconium materials, especially stricter control of the content of elements such as iron, chromium, and nickel, thus providing better corrosion resistance and more stable mechanical properties.
Q: How to properly store high-purity zirconium plates?
A: It is recommended to store in a dry, well-ventilated indoor environment to avoid contact with corrosive substances such as chloride ions. It is recommended to use anti-rust oil to protect the surface during long-term storage.
Q: What are the precautions for processing high-purity zirconium plates?
A: Special tools should be used during processing to avoid iron contamination; welding should be carried out under inert gas protection; carbide tools are recommended for cutting.
Why choose our high-purity zirconium 60702 plate?
Strict quality control: from raw materials to finished products, implement full-process quality control
Advanced manufacturing process: using vacuum arc melting and precision rolling technology
Complete testing equipment: equipped with high-end testing equipment such as spectrometers and metallographic microscopes
Professional application support: providing full-range technical support, such as material selection and processing technology
Flexible customization service: special specifications and surface treatment can be provided according to customer needs
Contact us for more information
For more technical details, price information, or sample applications about high-purity zirconium 60702 plate (99.9%), please feel free to contact our sales engineer team. We will provide you with professional material selection advice and technical support to help you find the solution that best suits your application needs. Email:linhui@lhtitanium.com
